This AC Triac Dimmer is compatible with all the Mi-Light / Mi-Boxer range of 2.4GHz wireless RF remote control handsets or wall panels. When paired through a compatible 2.4GHz Gateway or Hub, the single-channel receivers can also be paired to a smartphone application. The receivers also support third-party voice control products such as smart speakers.

The control receiver features auto transmitting & synchronising functions when multiple receivers are paired to the same zone on the controller. Provided they are all within 30m of each other and one unit is within 30m of the controller. All the receivers in the group will synchronise lighting together with no interconnecting control cables.

There is a connection for the "Push Switch" control enabling you to switch or dim your mains-powered lighting with a momentary hard-wired switch.

The switch will work with AC voltages of 100v - 240v AC with a maximum current of 1.36A. It will power products up to 300w at 220v AC.

For more information on this product and control options, please contact our sales team. Call, email or use our online live chat to talk to our technical sales team.

Shop our range of LED Controls through our website or contact our technical sales team.

Download Datasheet -TRIC1 Specification Sheet

Technical Specification
Product Code:    TRIC1
Product Packed:    Gift box
Manufacturer:    Mi-Light / MiBoxer
Product Type:    Controller / Receiver
IP Rating:    IP20 Non-Waterproof
Guarantee Period:    5 Years
Input Voltage:    100V - 240V AC
Output Voltage:    100V - 240V AC
Connectivity:    RF
Size:    L49mm x W49mm x H25mm
Dimmable:    No
Wireless Range:    Up to 30 metres
Transmitting Power:    6dBm
Operation Frequency:    2.4GHz
Operating Temp:    -10 to 40ºC
Total Output:    Max1.36A
Output Max:    150W @ 110V / 300W @ 220V
